76mm Particle Slurry Pump Impeller Liner 10/8ST- Single Suction

Product Categories
Shijiazhuang Neibuyeluo Import and Export Trading Co.,LTD
Contact Now

76mm Particle Slurry Pump Impeller Liner 10/8ST- Single Suction

Model Number : G

Place of Origin : China

MOQ : one

Price : 300USD-8000USD

Payment Terms : TT

Supply Ability : 100 per month

Delivery Time : 30-40days

Packaging Details : Wooden Package

Max particle size : 76mm

Pump type : 10/8ST-

Application : Gold mining,Iron ore transfering, tailing,coal mine

Input size : 10"

Output size : 8"

ODM : Available

Pump structure : Single-stage horizontal

Pump drive type : Motor or engine

Contact Now

Horizontal centrifugal wear-resistant gold mine 10/8ST- slurry pump impeller liner



Product Description

Impeller:  -The rotating wet part of slurry pump



Liner:       -The wet part forms the channel transfering the slurry.

                -The liner is inside the pump case



The material of impeller and liner is required abrasive-resistant. It is high chrome cast iron alloy, Cr26, Cr27, Cr28, A05, A07, A49.







Characteristics



Pump input diameter size: 10"
Pump output diameter size: 8"
Number of impeller blades: 5
Hardness : (HRC56-63)
Diameter of the impeller wheel: 737
Diameter of the impeller blades: 686
Pump thoery: Centrifugal

76mm Particle Slurry Pump Impeller Liner 10/8ST- Single Suction



Technology

High chrome alloy material

1. A05 is a wear resistant white iron that offers excellent performance under erosive conditions.The high abrasive-resistance of A05 is supported by the presence of hard carbides within its micro-structure. Alloy A05 is particularly suited to applications where mild corrosion resistance, as well as erosion resistance is required.
2. A07 Marten-sic white iron with moderate erosion resistance.
3. A49 is usually apply in low pH corrosion duties, where erosive-resistance is also needed. The alloy is particularly suitable for Flue Gas Desulphu-rization(FGD) and other corrosive applications, pH less than 4. A49 has an erosion resistance similar to that of Ni-Hard







Application

The material of the slurry pump impeller and liner is anti-abrasive. The slurry pump is use for ore slurry transfering in coal mining, gold mining, iron mining and copper mining. The impeller and volute liner is the replacement of warman 10/8st- type slurry pump wet parts. ODM is also available in our factory. Our experts are able to make cast mould according drawings.
